| 5~12 heating zone with both top and down heaters, and 2~3 cooling section
|
| Temperature setting:Max:350℃(Option :400℃)
|
| Both mesh belt and chain rail can be used for reflow process (Chain rail width Max:320mm and 520mm models)
|
| Excellent chamber seal design, minimized N2 consumption
|
| N2 and Air supply can be selected independently
|
| Computerized P.I.D temperature control
|
| It can be linked with a personal computer to set up, store, recall process parameters, and monitor/record temperature status
|
| Can operate without PC (PC is option)
|
| Independent Flux collecting device for each heating zone, collocate with special reusable metal filter, easy to maintain
|
| N2 low pressure alarm device
|
| Trace Oxygen analyzer (Option)
|
| Water cooling system(Option)
|
| Compatible with Lead-Free process
|
